NISSAN
“–…/
April 29, 2024
Ms. Eileen Sullivan
Associate Administrator for Enforcement
National Highway Traffic Safety Administration
Attn: Recall Management Division (NVS-215)
Room W48-302
1200 New Jersey Avenue, SE
Washington, D.C. 20590
Dear Ms. Sullivan:
Nissan North America, Inc.
One Nissan Way
Franklin, TN 37067
Mailing Address:
PO Box 685001
Franklin, TN 37068
We are transmitting the enclosed Defect Information Report in accordance with 49 CFR Part
573. A voluntary recall campaign will be initiated and your office provided with the notices.
Very truly,
Will Swindell
Manager,
Technical Compliance
Encl.
DEFECT INFORMATION REPORT
1. Manufacturer:
Nissan Mexicana, SA De CV. Aguascalientes Plant 2
2. Vehicles Potentially Involved:
Certain Model Year 2024 Nissan Sentra vehicles as shown in the table below:
Model Dates of Manufacture Plant
MY 2024 Nissan Sentra July 21, 2023 through January 18, 2024 Aguas 2
Based on internal Nissan records, the issue (as described in Section 5 below) occurred on
certain Model Year 2024 Sentra vehicles that were subject to a recent plant retro-fit
modification to replace the Continuously Variable Transmission (CVT) assembly. No other
Nissan or INFINITI vehicles are affected.
The name, description and part number of the subject components are below:
Part Name Part DescriRtion Part Number
Shaft Assy – Front Drive, Left-Hand Front Left-Hand Drive Shaft 39101 6LB0A
3. Total Number of Vehicles Potentially Involved:
Approximately 9,645 MY 2024 Nissan Sentra vehicles total.
4. Percentage of Vehicles Estimated to Actually Contain the Defect:
Approximately 0.14%. 1% is used here because submission within NHTSA’s safety portal will
not allow a value less than 1%.
5. Description of the Defect:
The front left-hand drive shaft on affected vehicles may not be fully seated to the CVT
assembly or may have a loose or missing retaining clip due to a potential installation error
during a retrofit activity at the plant. In this condition, transmission fluid could leak resulting
in reduced transmission fluid pressure, potential transmission jerking and/or hesitation,
and illumination of the Malfunction Indicator Lamp (MIL). There is potential risk under
certain circumstances that the drive shaft spline could fail to engage the differential gear in
the CVT, causing a loss of motive power without prior warning.
6. Chronology of Principal Events:
January 24, 2024 – Nissan received one (1) warranty report of a customer stating the
distance sensor warning light illuminated while driving a Model Year 2024 Sentra vehicle.
The investigation at the dealer initially identified fluid leaking from under the vehicle at the
driver’s side front axle. After further review, the transmission fluid leak originated at the
front left-hand side of the transmission assembly. When the left-hand drive shaft was
removed, the retaining clip was missing.
February 2024 – Nissan confirmed three (3) additional warranty claims of Model Year 2024
Sentra vehicles with front left-hand drive shaft not fully seated to the transmission,
resulting in a fluid leak and MIL “ON”. The investigation at the dealer found the vehicle’s drive
shaft was missing the retaining clip. Nissan launched an investigation and determined all
four (4) vehicles were previously included in a plant retrofit activity.
Nissan conducted a yard audit at the Aguascalientes Plant II to inspect the front left-hand
drive shaft on 514 Sentra vehicles that were previously repaired as part of the CVT retrofit
activity. The yard audit identified three (3) Sentra vehicles with a loose or missing clip at the
connection of the drive shaft to the transmission axle. Additionally, the drive shaft coupling
appeared to not be installed correctly.
March 12, 2024 – Nissan received one (1) additional warranty claim with the subject
condition and collected front left-hand drive shaft for analysis. Additionally, Nissan began
an assessment, including a warranty parts collection activity, to understand the potential
risk of this concern.
March 2024 – Nissan initiated a quality action on March 15, 2024 to dealerships for
inspection, and if necessary, repair of all potentially affected MY 2024 Sentra vehicles in
dealer inventory. Out of a total of 4,234 Sentra vehicles inspected as of April 24, 2024, 58
were found with the front left-hand drive shaft not fully seated to the transmission and
repaired. Nissan also conducted a pre-delivery activity at the rail yard to inspect for proper
drive shaft installation in certain MY 2024 Sentra vehicles.
April 2024 – Nissan received one (1) part from the warranty parts collection activity. The
inspection confirmed a loose retaining clip on the drive shaft.
Nissan’s assessment concluded that if the front left-hand side drive shaft is not fully seated
in the CVT assembly and the retaining clip is loose or missing, it can cause a fluid leak and
allow the pressure to become lower than expected. Under certain circumstances, the left

hand drive shaft could disengage from the CVT and can lead to a loss of motive power
without prior warning. In the event a drive shaft disengagement occurs, Nissan has
confirmed the drive shaft remains captured and does not fully separate from the
transmission.
April 22, 2024 – Nissan decided to conduct a Voluntary Safety Recall for all potentially
affected vehicles included in the retrofit activity.
Nissan has confirmed a total of 9 (nine) warranty claims related to the subject condition.
Nissan is not aware of any accident or injuries related to the subject condition.
7. Description of Corrective Action:
Dealers were notified of a Quality Action on March 15, 2024 and will be notified of the recall
beginning May 3, 2024.
Beginning June 20, 2024, owners of all potentially affected vehicles will be notified to bring
their Sentra to a Nissan dealer for inspection of the front left-hand drive shaft assembly:
If the drive shaft is installed correctly, no action is required.
If the drive shaft is not fully seated, the dealer will replace both the drive shaft and
CVT assembly.
All repairs will be performed free of charge for parts and labor. Inspection will take 30
minutes to conduct and if a replacement is necessary, the repair may take up to seven (7)
hours to complete.
Nissan will not include a statement in the Part 577 owner notification concerning
reimbursement for the cost of obtaining a pre-notification remedy since the subject
vehicles are under warranty.
8. Copy of Notices:
Copies of all notices will be provided to NHTSA as they become available.

**************************************************************************************************************

OMB Control No.: 2127-0004
Part 573 Safety Recall Report 24V-304
The information contained in this report was submitted pursuant to 49 CFR §573
Manufacturer Name : Submission Date :
Nissan North America, Inc. APR 29, 2024 NHTSA Recall No. : 24V-304 Manufacturer Recall No. : PMA37 Manufacturer Information :
Manufacturer Name : Nissan North America, Inc.
Address : P. O. BOX 685001
Franklin TN 37068-5009 Company phone : 800-647-7261
Population :
Number of potentially involved : 9,645 Estimated percentage with defect : 1 %
Vehicle Information : Vehicle 1 : 2024-2024 Nissan Sentra Vehicle Type : LIGHT VEHICLES Body Style : 4-DOOR Power Train : GAS
Descriptive Information : Based on internal Nissan records, the issue occurred on certain Model Year 2024 Sentra vehicles that were subject to a recent plant retro-fit modification to replace the Continuously Variable Transmission (CVT) assembly. No other Nissan or INFINITI vehicles are affected.
Production Dates : JUL 21, 2023 – JAN 18, 2024
VIN Range 1 : Begin : NR End : NR Not sequential Description of Defect :
Description of the Defect : The front left-hand drive shaft on affected vehicles may not be fully seated to the CVT assembly or may have a loose or missing retaining clip due to a potential installation error during a retrofit activity at the plant.
FMVSS 1 : NR FMVSS 2 : NR
Description of the Safety Risk : There is potential risk under certain circumstances that the drive shaft spline could fail to engage the differential gear in the CVT, causing a loss of motive power without prior warning.
Description of the Cause : NR Identification of Any Warning
that can Occur : In this condition, transmission fluid could leak resulting in reduced transmission fluid pressure, potential transmission jerking and/or hesitation, and illumination of the Malfunction Indicator Lamp (MIL).
Involved Components : Part 573 Safety Recall Report 24V-304 Page 2 Component Name 1 : Shaft Assy – Front Drive, Left-Hand Component Description : Front Left-Hand Drive Shaft Component Part Number : 39101 6LB0A Supplier Identification : Component Manufacturer
Name : NR Address : NR
NR
Country : NR Chronology :
See attached Part 573 for chronology details. Description of Remedy :
Description of Remedy Program : Owners of all potentially affected vehicles will be notified to bring their
Sentra to a Nissan dealer for inspection of the front left-hand drive shaft assembly:
• If the drive shaft is installed correctly, no action is required.
• If the drive shaft is not fully seated, the dealer will replace both the drive shaft and CVT assembly.
All repairs will be performed free of charge for parts and labor. Inspection will take 30 minutes to conduct and if a replacement is necessary, the repair may take up to seven (7) hours to complete. Nissan will not include a statement in the Part 577 owner notification concerning reimbursement for the cost of obtaining a pre-notification remedy since the subject vehicles are under warranty. How Remedy Component Differs NR from Recalled Component :
Identify How/When Recall Condition NR was Corrected in Production : The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 24V-304
Page 3
The information contained in this report was submitted pursuant to 49 CFR §573
Recall Schedule :
Description of Recall Schedule : Dealers were notified of a Quality Action on March 15, 2024 and will be
notified of the recall beginning May 3, 2024.
Beginning June 20, 2024, owners of all potentially affected vehicles will be notified to bring their Sentra to a Nissan dealer for inspection of the front left-hand drive shaft assembly.
Planned Dealer Notification Date : MAY 03, 2024 – NR Planned Owner Notification Date : JUN 20, 2024 – NR
* NR – Not Reported

**************************************************************************************************************

**************************************************************************************************************

**************************************************************************************************************
