Voluntary Safety Recall Campaign 2014-2016 Nissan Rogue; Wire Harness Connector Corrosion

SEOCONTENT-START

1/17 Classification: Reference: Date: EL22-001 NTB22-076 August 25, 2022 VOLUNTARY SAFETY RECALL CAMPAIGN 2014-2016 ROGUE; WIRE HARNESS CONNECTOR CORROSION CAMPAIGN ID #: R21B9 APPLIED VEHICLES: 2014-2016 Rogue (T32) Check Service COMM or Dealer Business Systems (DBS) National Service History to confirm campaign eligibility. INTRODUCTION Nissan is conducting this voluntary safety recall campaign, on certain specific model year 2014-2016 Rogue vehicles, to inspect and, if necessary, replace the Main Harness M74 to Body Harness B42 connector. This service will be performed at no charge to the customer for parts or labor. IDENTIFICATION NUMBER Nissan has assigned identification number R21B9 to this campaign. This number must appear on all communication and documentation of any nature dealing with this campaign. DEALER RESPONSIBILITY It is the dealer’s responsibility to check Service COMM or Dealer Business Systems (DBS) National Service History for the campaign status on each vehicle falling within the range of this voluntary safety recall which for any reason enters the service department. This includes vehicles purchased from private parties or presented by transient (tourist) owners and vehicles in a dealer’s inventory. Federal law requires that new vehicles in dealer inventory which are the subject of a safety recall must be corrected prior to sale. Failure to do so can result in civil penalties by the National Highway Traffic Safety Administration. While federal law applies only to new vehicles, Nissan strongly encourages dealers to correct any used vehicles in their inventory before they are retailed. Nissan Bulletins are intended for use by qualified technicians, not ‘do-it-yourselfers’. Qualified technicians are properly trained individuals who have the equipment, tools, safety instruction, and know-how to do a job properly and safely. NOTE: If you believe that a described condition may apply to a particular vehicle, DO NOT assume that it does. See your Nissan dealer to determine if this applies to your vehicle. 2/17 NTB22-076 REPAIR OVERVIEW IMPORTANT: The purpose of REPAIR OVERVIEW (above) is to give you a quick idea of the work you will be performing. You MUST closely follow the entire SERVICE PROCEDURE as it contains information that is essential to successfully completing this repair. No evidence of corrosion present. There is evidence of corrosion present. Use Service Comm (Campaign ID # R21B9) to confirm the vehicle you are working on is affected by this campaign Replace both wire harness connectors (M74 and B42). Step 11 on page 8 Apply white lithium grease to M74 and B42 wire harness connectors Step 20 on page 12 END Inspect the Main Harness M74 and Body Harness B42 wire harness connectors for evidence of corrosion. Step 10 on page 7 Remove the foam and vinyl wire harness covering from the B42 wire harness connector branch. Step 9 on page 6 3/17 NTB22-076 REQUIRED SPECIAL TOOLS  Flameless Heat Gun, special tool J-46538. o The flameless heat gun is no longer available from Tech•Mate, an equivalent tool may be used. Figure 1  Crimping Pliers, special tool J-48817-8, for aluminum wire repair. o Provided in the aluminum wire repair kit J-48817-AL-KIT.  New part number NI-48817-AL-KIT. Figure 2  Terminal Release Tool, special tool J-48817-1. o New part number NI-48817-1. Figure 3  Additional tools may be purchased from Tech•Mate online: techmatetools.com, or by phone: 1-833-397-3493. 4/17 NTB22-076 SERVICE PROCEDURE Inspection 1. Write down the radio settings. Presets 1 2 3 4 5 6 AM FM 1 FM 2 XM 1 XM 2 XM 3 Bass Treble Balance Fade Speed Sen. Vol. 2. If equipped, write down the customer settings for the ATC (Automatic Temperature Control) system. 3. Turn the ignition OFF. 4. Disconnect the negative battery cable. 5. Remove the driver (LH) side inner front kicking plate.  Refer to the ESM: BODY INTERIOR > INTERIOR > REMOVAL AND INSTALLATION > BODY SIDE TRIM > KICKING PLATE 6. Remove the driver side dash side finisher.  Refer to the ESM: BODY INTERIOR > INTERIOR > REMOVAL AND INSTALLATION > BODY SIDE TRIM > DASH SIDE FINISHER 5/17 NTB22-076 7. Disconnect the M74 wire harness connector from the B42 wire harness connector. Figure 4 8. Pull the B42 wire harness connector toward the rear of the vehicle to disengage the connector from the connector bracket. Figure 5 B42 wire harness connector M74 wire harness connector B42 wire harness connector Connector bracket 6/17 NTB22-076 9. Remove and discard the foam and vinyl wire harness covering from the B42 wire harness connector wire branch. Figure 6 Figure 7 Figure 8 B42 wire harness connector Foam and vinyl covering Foam and vinyl covering Foam and vinyl covering removed B42 wire harness connector B42 wire harness connector 7/17 NTB22-076 10. Inspect the M74 and B42 wire harness connectors for any signs of corrosion (Figure 9 – Figure 13).  If signs of corrosion are found, proceed to step 11 on page 8 to replace both M74 and B42 wire harness connectors.  If there are no signs of corrosion, skip to step 20 on page 12 to apply white lithium grease to both wire harness connectors. Examples of Corrosion Figure 9 Figure 10 Figure 11 Figure 12 Figure 13 Corrosion Corrosion Corrosion Corrosion Corrosion 8/17 NTB22-076 Wire Harness Connector Replacement 11. Replace the M74 and B42 wire harness connectors as follows: a. Starting with the M74 wire harness connector, cut and splice in the new wire harness connector, one wire at a time. IMPORTANT:  Some vehicles may not utilize all circuits in the replacement connectors.  The length of the unused wires should be trimmed to an appropriate length and secured to the harness branch with electrical tape.  Be sure to stagger, or offset, each cut wire so that the wire repair terminal crimps are not all in the same area.  Some of the wire colors on the replacement connector may not match the vehicle’s connectors. Be sure to verify the terminal positions are the same between both connectors when splicing in the new wire harness connector. b. Use the aluminum wire repair terminal crimps and heat shrink provided in the wire harness repair kit to attach all wires. IMPORTANT:  Do not use solder sleeves for this repair. The parts provided in the wire harness repair kit must be used.  Each wire harness repair kit includes two (2) different sized repair terminal crimps and 2 different sized heat shrink tubing. Be sure the correct size repair terminal crimp and heat shrink tubing is used with the correct sized wire.  If needed, refer to Quick Reference for Performing Wire Repairs on Aluminum Wiring on page 9. c. Wrap the wire and heat shrink with electrical tape to prevent water from entering. IMPORTANT: Do not wrap the electrical tape up the harness branch, only apply electrical tape over the aluminum wire terminal crimp. d. Repeat a, b, and c above for all the wires in the M74 and B42 wire harness connectors, and then skip to step 19 on page 11. 9/17 NTB22-076 Quick Reference for Performing Wire Repairs on Aluminum Wiring Figure 14 Figure 15 Figure 16 12. Insert the heat shrink (2) over the aluminum wires (1) that will be repaired.  Strip off 10mm of the wire insulation and then install the appropriate size aluminum wire crimp (3). 13. Insert the aluminum wire crimp into the appropriate crimp size of the Crimping Pliers, special tool J-48817-8. 14. Press the handles of the Crimping Pliers, special tool J-48817-8, until the handles are released automatically. NOTE: If the crimping tool handles do not release automatically, the aluminum wire crimp has not been crimped properly. 10/17 NTB22-076 Figure 17 Figure 18 Figure 19 15. After crimping the aluminum wires in the aluminum crimp, make sure that the wires do not come out of the aluminum crimp when pulling on the wires from both sides. 16. Slide the heat shrink over the aluminum crimp and heat the heat shrink using the Flameless Heat Gun, special tool J-46538, or equivalent. 17. After heating the heat shrink, make sure that there are signs of sealant (A) around each edge of the heat shrink. 11/17 NTB22-076 Figure 20 Figure 21 18. Wrap the wire and heat shrink with electrical tape (A) to prevent water from entering. IMPORTANT: Only apply the electrical tape over the aluminum wire terminal crimp. 19. Once all of the wires have been connected, secure the wire harness together with electrical tape.  The length of the unused wires should be trimmed to an appropriate length and secured to the harness branch with electrical tape. IMPORTANT: Do not wrap the electrical tape up the harness branch, only apply the electrical tape over the aluminum wire terminal crimp. 12/17 NTB22-076 Apply White Lithium Grease to the M74 and B42 Wire Harness Connectors To avoid damage to the vehicle’s interior, be careful not to get grease on any interior components. 20. Using the 04A tool of the Terminal Release Tool, special tool J-48817-1 (Figure 22), remove the Terminal Position Assurance (TPA) from the B42 wire harness connector.  The TPA release is located on the harness side of the B42 wire harness connector (Figure 23). 21. Insert the 04A tool into the TPA release, and then push the TPA toward the terminal side of the wire harness connector, as shown in Figure 24. IMPORTANT: Be careful not to break or damage the TPA, they are not available as an individual part. NOTE: There are two (2) separate retainers that secure the TPA. The first retainer will release, and then the TPA will move forward slightly and stop. o Continue to push the TPA toward the terminal side of the connector to disengage the second retainer. o Once both TPA retainers have been released, the TPA can be removed. Figure 24 Figure 22 Figure 23 04A tool Terminal Release Tool TPA release Terminal Release Tool TPA release TPA B42 wire harness connector 13/17 NTB22-076 Figure 25 Figure 26 22. Apply white lithium grease to the B42 wire harness connector.  Apply grease around all sides of all terminals in the connector, making sure the level of the grease comes up to the top of the terminals, as shown in Figure 25. 23. Reinstall the TPA into the B42 wire harness connector. a. Wrap a shop towel or cloth around the wire harness connector. b. Using a small flat-blade screw driver, carefully push the TPA down until it is fully seated. c. Wipe off the excess grease from the sides of the wire harness connector. TPA White lithium grease B42 wire harness connector B42 wire harness connector 14/17 NTB22-076 24. Using the 04A tool of the Terminal Release Tool, special tool J-48817-1, disengage the TPA from the M74 wire harness connector, as shown in Figure 27. a. Carefully pry upward on one of the corners of the TPA to release the first retainer. b. Repeat for the opposite corner. c. Using your hand, carefully pull the TPA straight outward to release the secondary retainer, and then remove the TPA. Figure 29 Figure 27 Figure 28 25. Apply white lithium grease to the M74 wire harness connector.  Only add enough grease to coat the terminals, as shown in Figure 29. 04A tool TPA TPA White lithium grease M74 wire harness connector M74 wire harness connector M74 wire harness connector 15/17 NTB22-076 Figure 30 27. Re-connect the M74 wire harness connector to the B42 wire harness connector.  Wipe off the excess grease from the sides of the M74/B42 wire harness connectors. 28. Reattach the B42 wire harness connector to the wire harness connector holding bracket. Vehicle Reassembly 29. Reinstall the dash side finisher.  Refer to the ESM: BODY INTERIOR > INTERIOR > REMOVAL AND INSTALLATION > BODY SIDE TRIM > DASH SIDE FINISHER 30. Reinstall the inner kicking plate.  Refer to the ESM: BODY INTERIOR > INTERIOR > REMOVAL AND INSTALLATION > BODY SIDE TRIM > KICKING PLATE 31. Re-connect the negative battery cable. 32. Reset the clock, radio settings, and if equipped, the ATC settings. 26. Reinstall the TPA into the M74 wire harness connector. a. Wrap a shop towel or cloth around the wire harness connector. b. Position the TPA over the wire harness connector and carefully push it into place. c. Wipe off the excess grease from the sides of the wire harness connector. TPA M74 wire harness connector 16/17 NTB22-076 33. Initialize the driver’s power window as follows: a. Turn the ignition ON (keep the transmission in Park and the parking brake applied). b. Close the door. c. Hold DOWN the power window switch to fully open the window. d. Hold UP the power window switch to fully close the window. e. Continue pulling the power window switch UP for 3 seconds after the glass stops at fully closed position. f. Check that auto-up function operates normally. 17/17 NTB22-076 PARTS INFORMATION DESCRIPTION PART NUMBER QUANTITY KIT – ENGINE ROOM HARNESS (US BUILT VEHICLE, 11th Character of the VIN is C) 240R2-6RR0A 1 KIT – ENGINE ROOM HARNESS (KOREAN BUILT VEHICLE, 11th Character of the VIN is P) 240R2-6RR0B 1 GREASE TUBE 60918-6RR0A (1) As Needed (2) (1) Order this item through the Nissan Maintenance Advantage program: Phone 877-NISNMA1 (877-647-6621). Website order via link on the dealer portal; www.NNAnet.com and click on the “Maintenance Advantage-Tire/Battery/Chemical” link. (2) One tube of grease will repair up to 10 vehicles. CLAIMS INFORMATION Submit a “CM” line claim using the following claims coding: CAMPAIGN (“CM”) ID DESCRIPTION OP CODE FRT R21B9 Inspect Wire Harness Connectors (OK Condition) and Apply White Lithium Grease R21B90 0.3 Inspect and Replace Wire Harness Connectors and Apply White Lithium Grease R21B91 2.0 EXPENSE CODE EXPENSE CODE DESCRIPTION MAX AMOUNT 015 Grease $0.72 AMENDMENT HISTORY PUBLISHED DATE REFERENCE DESCRIPTION August 25, 2022 NTB22-076 Original bulletin published

**************************************************************************************************************

**************************************************************************************************************
