Classification: Reference: Date:
KS23-002 NTB23-028 March 23, 2023
Bulletins are intended for use by qualified technicians, not ‘do-it-yourselfers’. Qualified technicians are
properly trained individuals who have the equipment, tools, safety instruction, and know-how to do a job
properly and safely. NOTE: If you believe that a described condition may apply to a particular vehicle, DO
NOT assume that it does. See your Nissan dealer to determine if this applies to your vehicle.
1/5
VOLUNTARY SAFETY RECALL CAMPAIGN
2014-2020 ROGUE AND 2017-2022 ROGUE SPORT;
MECHANICAL KEY
CAMPAIGN ID #: R22C8
APPLIED VEHICLES: 2014-2020 Rogue (T32)
2017-2022 Rogue Sport (J11)
APPLIED GRADES: S
Check Service COMM or Dealer Business Systems (DBS)
National Service History to confirm campaign eligibility.
INTRODUCTION
Nissan is conducting this voluntary safety recall campaign on certain specific model year
2014-2020 Rogue and 2017-2022 Rogue Sport vehicles to install a set screw into the keys.
This service will be performed at no charge to the customer for parts or labor.
IDENTIFICATION NUMBER
Nissan has assigned identification number R22C8 to this campaign. This number must
appear on all communication and documentation of any nature dealing with this campaign.
DEALER RESPONSIBILITY
It is the dealer’s responsibility to check Service COMM or Dealer Business Systems (DBS)
National Service History for the campaign status on each vehicle falling within the range of
this voluntary safety recall which for any reason enters the service department. This
includes vehicles purchased from private parties or presented by transient (tourist) owners
and vehicles in a dealer’s inventory. Federal law requires that new vehicles in dealer
inventory which are the subject of a safety recall must be corrected prior to sale.
Failure to do so can result in civil penalties by the National Highway Traffic Safety
Administration. While federal law applies only to new vehicles, Nissan strongly
encourages dealers to correct any used vehicles in their inventory before they are retailed.
2/5 NTB23-028
REPAIR OVERVIEW
Use Service Comm to confirm if Campaign R22C8 is open
YES
This bulletin does
not apply
NO
Install a set screw
into each key
Repair complete
3/5 NTB23-028
SERVICE PROCEDURE
IMPORTANT: The key blade will no longer fold once the set screw is installed. This is
normal and expected.
Figure 1
Figure 2
1. Depress the key release button
and fold the key blade out.
 Verify the key blade is extended
and in the locked position.
2. Orient the key so that the key blade
storage slot is visible.
Key release
button
Key blade
storage slot
4/5 NTB23-028
Figure 3
Figure 4
4. Repeat steps 1–3 on pages 3–4 for any additional keys.
3. Using a suitable 3/32″ hex wrench,
position the set screw against the
silver portion of the key.
 The set screw will cut new
threads into the key housing.
 While keeping the set screw
straight, thread it down into the
key blade storage slot until the
top of the set screw is even with
the lower ledge in the key blade
storage slot.
Set screw
Key blade
storage slot
Set screw
5/5 NTB23-028
PARTS INFORMATION
DESCRIPTION PART NUMBER QUANTITY
BOLT-STUD – SET SCREW 01151-0021U As needed
CLAIMS INFORMATION
Submit a “CM” line claim using the following claims coding:
CAMPAIGN (“CM”) ID DESCRIPTION OP CODE FRT
R22C8 Install Set Screw Into Keys R22C80 0.2
AMENDMENT HISTORY
PUBLISHED DATE REFERENCE DESCRIPTION
March 23, 2023 NTB23-028 Original bulletin published

**************************************************************************************************************

Classification: Reference: Date:
KS23-002A NTB23-028A August 29, 2023
1/1
VOLUNTARY SAFETY RECALL CAMPAIGN
2014-2020 ROGUE AND 2017-2022 ROGUE SPORT;
MECHANICAL KEY
CAMPAIGN ID #: R22C8
APPLIED VEHICLES: 2014-2020 Rogue (T32)
2017-2022 Rogue Sport (J11)
APPLIED GRADES: S
AMENDMENT HISTORY
PUBLISHED DATE REFERENCE DESCRIPTION
March 23, 2023 NTB23-028 Original bulletin published
August 29, 2023 NTB23-028A Bulletin no longer active
Recall Campaign ID # R22C8 has been superseded by
Recall Campaign ID # R22C9 (NTB23-068) and is no longer active.
 Repair orders opened after this bulletin’s published date are no longer eligible
for reimbursement under Campaign ID # R22C8.
 Discard all previous versions of NTB23-028.

**************************************************************************************************************
