VOLUNTARY SAFETY RECALL CAMPAIGN – Rear Propeller Shaft Replacement – 2011-2013 Infiniti M56, 2012-2013 M35 Hybrid, & 2014 Q70 & Q70 Hybrid

Classification:	Reference:	Date:
PD20-003	ITB20-028	December 7, 2020



VOLUNTARY SAFETY RECALL CAMPAIGN
REAR PROPELLER SHAFT REPLACEMENT

CAMPAIGN ID #:	R20B8
APPLIED VEHICLES:	2011-2013 M56 (Y51) 2012-2013 M35 Hybrid (HY51) 2014 Q70 (Y51) 2014 Q70 Hybrid (HY51)



APPLIED ENGINE:	VK56 and VQ35
APPLIED DRIVETRAIN:	RWD only



Check Service COMM or Dealer Business Systems (DBS)  National Service History to confirm campaign eligibility.



INTRODUCTION

Infiniti is conducting this voluntary safety recall campaign, on certain specific model year 2011-2013 M56, 20122013 M35 Hybrid, and 2014 Q70 and Q70 Hybrid vehicles, to replace the rear propeller shaft. This service will be performed at no charge to the customer for parts or labor.



IDENTIFICATION NUMBER

Infiniti has assigned identification number R20B8 to this campaign. This number must appear on all communication and documentation of any nature dealing with this campaign.



RETAILER RESPONSIBILITY

It is the  retailer’s responsibility to check Service COMM or Dealer Business Systems (DBS) National Service History for the campaign status on each vehicle falling within the range of this voluntary safety recall which for any reason enters the service department. This includes vehicles purchased from private parties or presented by transient (tourist) owners and vehicles in a retailer’s inventory.  Federal law requires that new vehicles in retailer inventory which are the subject of a safety recall must be corrected prior to sale.  Failure to do so can result in civil penalties by the National Highway Traffic Safety Administration.  While federal law applies only to new vehicles, Infiniti strongly encourages retailers to correct any used vehicles in their inventory before they are retailed.



SERVICE PROCEDURE



1. Replace the rear propeller shaft.



• For propeller shaft replacement, refer to the Electronic Service Manual (ESM) section:

TRANSMISSION DRIVELINE > DRIVELINE > REAR PROPELLER SHAFT 3S80A-R > REMOVAL AND INSTALLATION > REAR PROPELLER SHAFT > REMOVAL AND INSTALLATION.



PARTS INFORMATION

MODEL		DESCRIPTION	PART NUMBER	QUANTITY
ALL		NUT (1)	01225-00062	2
		NUT-FIX, PROPELLER SHAFT (1)	37171-AL60A	4
		WASHER-LOCK (1)	37121-JK20B	4
		BOLT-FIX, PROPELLER SHAFT (1)	37120-AH00A	4
VQ35	M35H	PROPELLER SHAFT	C7000-1MG0B	1
	Q70 Hybrid	PROPELLER SHAFT	C7000-3WG0B	1
VK56	M56	PROPELLER SHAFT	C7000-1MC1B	1
	Q70



(1)   Single-use part



CLAIMS INFORMATION

Submit a “CM” line claim using the following claims coding:

CAMPAIGN (“CM”) ID	DESCRIPTION	OP CODE	FRT
R20B8	Replace Rear Propeller Shaft	R20B80	1.0 hr



AMENDMENT HISTORY

PUBLISHED DATE	REFERENCE	DESCRIPTION
December 7, 2020	ITB20-028	Original bulletin published



---

Remedy Instructions and TSB

RCRIT-20V755-0613.pdf 133.471KB



---

Latest Recalls Documents

For the Latest and Most Recent Recalls Information Visit the link below…

https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=20V755&docType=RCL



---
